Description
We supply large quantity of Nozzles for SONY E2000 F209 Pick and Place machine. Both of original and alternative nozzless are available.
The good quality and competitive price of SONY E2000 F209 SMT SMD NOZZLE AF12082 AF12082F1 will save your money on the consumables.
If you are looking for A-1081-951-B, please send us your RFQ or submit your inquiry at the “Ask for a quotation” tag.
The nozzles listed below are the common nozzle, if you cannot find what you are looking for, please send us your drawing of nozzles.
We offer nozzles for SONY E1000/E1100 SMT Machine.
| No. | Part Number | Nozzle Model | Components |
| 1 | A-8336-436-A | NOZZLE CF12080 | 2012, 3216, Tantal-A |
| 2 | A-8417-236-A | NOZZLE CF20150 | VOLφ3, Tantal-A |
| 3 | A-8336-437-A | NOZZLE CF25200 | VOLφ3, Tantal-A |
| 4 | A-8336-438-A | NOZZLE CF30250 | VOLφ4, Tantal-C,D, Al-con. |
| 5 | A-8336-439-A | NOZZLE CF60500 | ~□ 16mm |
| 6 | A-8336-440-A | NOZZLE CF00900 | □ 16mm ~ 55mm, PLCC |
| 7 | A-8417-175-A | NOZZLE CFREC01 | Square type of connectors |
| 8 | A-8417-176-A | NOZZLE CFREC02 | Square type of connectors |
| 9 | A-8417-177-A | NOZZLE CFREC03 | Square type of connectors |
| 10 | A-8417-178-A | NOZZLE CFREC04 | Square type of connectors |
| 11 | A-8417-237-A | NOZZLE CFREC05 | Square type of connectors |
| 12 | A-8417-238-A | NOZZLE CFREC06 | Square type of connectors |
| 13 | A-8417-239-A | NOZZLE CFREC07 | Square type of connectors |
| 14 | A-8417-240-A | NOZZLE CFREC08 | Square type of connectors |
| 15 | A-8417-241-A | NOZZLE CFREC09 | Square type of connectors |
| 16 | A-8417-242-A | NOZZLE CFREC10 | Square type of connectors |
| 17 | A-8417-243-A | NOZZLE CFREC11 | Square type of connectors |
| 18 | A-8417-244-A | NOZZLE CFSID01 | Odd shape |
| 19 | A-8417-245-A | NOZZLE CFOFF01 | |
| 20 | A-8417-234-A | NOZZLE CF6010G | Component Odd shape |
| 21 | A-8417-229-A | NOZZLE CF6020G | Odd shape |
| 22 | A-8417-232-A | NOZZLE CF6A20G | Odd shape |
| 23 | A-8417-233-A | NOZZLE CF6A2AG | Odd shape |
| 24 | A-8417-235-A | NOZZLE CF9010G | Odd shape |
| 25 | A-8417-230-A | NOZZLE CF9020G | Odd shape |
| 26 | A-8417-231-A | NOZZLE CF9070G | Odd shape |
| 27 | A-8417-328-A | NOZZLE CFAD001 | Adaptor for CF12080 for chip component |
| 28 | A-8417-390-A | CB65500 | □ 8mm ~ |
| 29 | A-8417-388-A | NOZZLE CF30200 | □ 5mm ~ |
| 30 | A-8417-388-A | NOZZLE CF30200 | □ 4mm ~ |
| 31 | A-8417-387-A | NOZZLE CB12080 | 3216 ~ |
We offer nozzles for SONY E1000/E1100 SMT Machine.
| No. | Part Number | Nozzle Model | Components |
| 1 | A-8417-333-A | NOZZLE AF05021 | 0603 (0201) |
| 2 | A-8417-334-A | NOZZLE AF06040 | 1005 (0402) |
| 3 | A-8417-335-A | NOZZLE AF06041 | 1005 (0402) |
| 4 | A-8417-336-A | NOZZLE AF08050 | 1608 (0603) |
| 5 | A-8417-337-A | NOZZLE AF10070 | 1608 (0603) – 3216 (0804) |
| 6 | A-8417-338-A | NOZZLE AF10071 | 1608 (0603) – 3216 (0804) |
| 7 | A-8417-339-A | NOZZLE AF12080 | 2012 to 3.9sq.mm |
| 8 | A-8417-340-A | NOZZLE AF25200 | 4sq.mm to 6sq.mm |
| 9 | A-8417-341-A | NOZZLE AF40300 | 5sq.mm to 7sq.mm |
| 10 | A-8417-342-A | NOZZLE AF60400 | 7sq.mm to 25sq.mm |
| 11 | A-8417-332-A | NOZZLE AB12080 | 2012 – 3216 |
| 12 | A-8417-433-A | NOZZLE AB25200 | 4sq.mm to 6sq.mm |
| 13 | A-8417-432-A | NOZZLE AB40300 | 5sq.mm to 7sq.mm |
| 14 | A-8417-434-A | NOZZLE AB60400 | 7sq.mm to 25sq.mm |
Updated Date: 2023-04-25
