Fuji NXT AIM H08 H12 Nozzle Ceramic Tip 1.30mm AA20A00

Fuji NXT AIM H08 H12 Nozzle Ceramic Tip 1.30mm AA20A00
Used for: FUJI NXT NXTII NXTIII AIM Pick and Place machine.
Condition: New, Original or Alternate
Part Number: AA20A00
Availability: 48 hours to 2 weeks depending on ordering quantity.

SKU: FUJI-NXT-3004 Categories: , Tag:
Thank you for sharing good thing

Description

We supply large quantity of Nozzles for FUJI NXT NXTII NXTIII AIM Pick and Place machine. Both of original and alternative nozzless are available.
The good quality and competitive price of Fuji NXT AIM H08 H12 Nozzle Ceramic Tip 1.30mm AA20A00 will save your money on the consumables.
If you are looking for AA20A00, please send us your RFQ or submit your inquiry at the “Ask for a quotation” tag.
The nozzles listed below are the common nozzle, if you cannot find what you are looking for, please send us your drawing of nozzles.

Fuji NXT H24-NOZZLE list

No.Part NumberPart NameRemarksRating
12AGKNX005105NOZZLEConsumable PartsR047-002-037
22AGKNX005205NOZZLEConsumable PartsR047-003-037
32AGKNX005304NOZZLEConsumable PartsR047-0035-037
42AGKNX005404NOZZLEConsumable PartsR047-004-037
52AGKNX005503NOZZLEConsumable PartsR047-005-037
62AGKNX003107NOZZLEConsumable PartsR047-007-035
72AGKNX006303NOZZLEConsumable PartsR047-008-035
82AGKNX003507NOZZLEConsumable PartsR047-010-035
92AGKNX001706NOZZLEConsumable PartsR047-013-035
102AGKNX003706NOZZLEConsumable PartsR047-018-035
112AGKNX003907NOZZLEConsumable PartsR047-025-035
122AGKNX004901NOZZLEDUMMY,Consumable PartsR047-DUMMY
132AGKNX004005NOZZLEФ1.3MELF，Consumable PartsR047-013M-035
142AGKNX004105NOZZLEФ1.8MELF，Consumable PartsR047-018M-035
152AGKNX004206NOZZLEФ2.5MELF，Consumable PartsR047-025M-035
162AGKNX001407NOZZLEФ2.5G，Consumable PartsR047-025G-035
172AGKNX007501NOZZLEWRS, Consumable PartsR047-006WRS-037
182AGKNX007602NOZZLEWRM, Consumable PartsR047-011WRM-035
192AGKNX007703NOZZLEWRL, Consumable PartsR047-018WRL-035

Fuji NXT H08/H12/V12/DX(R12) NOZZLE list

No.Part NumberPart NameRemarksRating
1A1AT17NOZZLEConsumable PartsR07-003-070
2A05615NOZZLEConsumable PartsR07-004-070
3A05716NOZZLEConsumable PartsR07-007-070
4A05816NOZZLEConsumable PartsR07-010-070
5A20A16NOZZLEConsumable PartsR07-013-070
6A20B15NOZZLEConsumable PartsR07-018-070
7A20C15NOZZLEConsumable PartsR07-025-070
8A20D15NOZZLEConsumable PartsR07-037-070
9A20E15NOZZLEConsumable PartsR07-050-070
10AA06417NOZZLEФ1.3MELF，Consumable PartsR07-013M-070
11AA19G17NOZZLEФ1.8MELF，Consumable PartsR07-018M-070
12AA06517NOZZLEФ2.5MELF，Consumable PartsR07-025M-070
132AGKNG004904NOZZLEConsumable PartsR07-0035-070
142AGKNG004105NOZZLEConsumable PartsR07-005-070
152AGKNG009703NOZZLEConsumable PartsR07-008-070
16AA0WT15NOZZLEФ2.5G，Consumable PartsR07-025G-070
17AA18C17NOZZLEФ3.7G，Consumable PartsR07-037G-070
18PB30312SHIM
19H1194KPAD, VACUUMKPA-2-N
20AA06316NOZZLEФ5.0G，Consumable PartsR07-050G-070
21PB30312SHIM
22H1339BPAD, VACUUMKPA-3.5-N
232AGKNG014901NOZZLEФ0.5C，Consumable PartsR07-005C-070
242AGKNG020801NOZZLEФ0.5CS，Consumable PartsR07-005-070
252AGKNG021601NOZZLEWRS, Consumable PartsR07-006WRS-070
262AGKNG021701NOZZLEWRM, Consumable PartsR07-011WRM-070
272AGKNG021804NOZZLEWRL, Consumable PartsR07-018WRL-070

FUJI NXT H08M-NOZZLES list

No.Part NumberPart NameRemarksRating
1AA8LS08NOZZLEConsumable PartsR19-004-155-M
2PZ55161FILTERConsumable Parts
3AA8DX12NOZZLEConsumable PartsR19-007-155-M
4PZ55161FILTERConsumable Parts
5AA8LT09NOZZLEConsumable PartsR19-010-155-M
6PZ55161FILTERConsumable Parts
7AA8DY12NOZZLEConsumable PartsR19-013-155-M
8PZ55161FILTERConsumable Parts
9AA8LW08NOZZLEConsumable PartsR19-018-155-M
10PZ55161FILTERConsumable Parts
11AA8LX09NOZZLEConsumable PartsR19-025-155-M
12PZ55161FILTERConsumable Parts
13AA8LY09NOZZLEConsumable PartsR19-037-155-M
14PZ55161FILTERConsumable Parts
15AA8LZ13NOZZLEConsumable PartsR19-050155-M
16PZ55161FILTERConsumable Parts
17AA8MA09NOZZLEConsumable PartsR19-070-155-M
18PZ55161FILTERConsumable Parts
19AA8MB07NOZZLEConsumable PartsR19-100-155-M
20PZ55161FILTERConsumable Parts
21AA8MC07NOZZLEConsumable PartsR19-150-155-M
22PZ55161FILTERConsumable Parts
23AA8MD07NOZZLEConsumable PartsR19-200-155-M
24PZ55161FILTERConsumable Parts
25AA8MN05NOZZLEConsumable PartsR19-013M-155-M
26PZ55161FILTERConsumable Parts
27AA8MR05NOZZLEConsumable PartsR19-018M-155-M
28PZ55161FILTERConsumable Parts
29AA8MS05NOZZLEConsumable PartsR19-025M-155-M
30PZ55161FILTERConsumable Parts
31AA8ME07NOZZLEConsumable PartsR19-025G-155-M
32PZ55161FILTERConsumable Parts
33AA8MF06NOZZLEConsumable PartsR19-037G-155-M
34PZ55161FILTERConsumable Parts
35AA8MG07NOZZLEConsumable PartsR19-050G-155-M
36PZ55161FILTERConsumable Parts
37AA8MH07NOZZLEConsumable PartsR19-070G-155-M
38PZ55161FILTERConsumable Parts
39AA8MK07NOZZLEConsumable PartsR19-100G-155-M
40PZ55161FILTERConsumable Parts
41AA8ML05NOZZLEConsumable PartsR19-150G-155-M
42PZ55161FILTERConsumable Parts
43PB31612SHIM
44PG01631PAD, VACUUM
45AA8MM04NOZZLEConsumable PartsR24-200-155-M
46PZ55161FILTERConsumable Parts
47PB31732SHIM
48PG01641PAD, VACUUM
492AGKNK009402NOZZLER19-23-10-155M
50PZ55161FILTER
512AGKNK009502NOZZLER19-31-10-155M
52PZ55161FILTER
532AGKNK009602NOZZLER19-43-10-155M
54PZ55161FILTER
552AGKNK009702NOZZLER19-31-13-155M
56PZ55161FILTER
572AGKNK009802NOZZLER19-43-13-155M
58PZ55161FILTER
592AGKNK009902NOZZLER19-59-13-155M
60PZ55161FILTER
612AGKNK010002NOZZLER19-44-18-155M
62PZ55161FILTER
632AGKNK010102NOZZLER19-60-18-155M
64PZ55161FILTER
652AGKNK010202NOZZLER19-84-18-155M
66PZ55161FILTER
672AGKNK010302NOZZLER19-61-25-155M
68PZ55161FILTER
692AGKNK010402NOZZLER19-85-25-155M
70PZ55161FILTER
712AGKNK010502NOZZLER19-115-25-155M
72PZ55161FILTER 4EobCTy5 4EobCTy5
732AGKNK010602NOZZLER19-87-37-155M
74PZ55161FILTER
752AGKNK010702NOZZLER19-117-37-155M
76PZ55161FILTER
772AGKNK010802NOZZLER19-118-50-155M
78PZ55161FILTER

FUJI NXT H04S-NOZZLES list

No.Part NumberPart NameRemarksRating
1AA8WT09NOZZLEConsumable PartsR19-010-155-S
2PZ55161FILTERConsumable Parts
3AA8TE09NOZZLEConsumable PartsR19-013-155-S
4PZ55161FILTERConsumable Parts
5AA8WW09NOZZLEConsumable PartsR19-018-155-S
6PZ55161FILTERConsumable Parts
7AA8WX09NOZZLEConsumable PartsR19-025-155-S
8PZ55161FILTERConsumable Parts
9AA93W08NOZZLEConsumable PartsR19-037-155-S
10PZ55161FILTERConsumable Parts
11AA93X08NOZZLEConsumable PartsR19-050-155-S
12PZ55161FILTERConsumable Parts
13AA93Y10NOZZLEConsumable PartsR19-070-155-S
14PZ55161FILTERConsumable Parts
15AA8WY09NOZZLEConsumable PartsR19-100-155-S
16PZ55161FILTERConsumable Parts
17AA8WZ08NOZZLEConsumable PartsR19-150-155-S
18PZ55161FILTERConsumable Parts
19AA9NZ06NOZZLEФ1.3MELF，Consumable PartsR19-013M-155-S
20PZ55161FILTERConsumable Parts
21AA9RA06NOZZLEФ1.8MELF，Consumable PartsR19-018M-155-S
22PZ55161FILTERConsumable Parts
232AGKNY001405NOZZLEФ2.5MELF，Consumable PartsR19-025M-155-S
24PZ55161FILTERConsumable Parts
25AA8XA10NOZZLEФ2.5G，Consumable PartsR19-025G-155-S
26PZ55161FILTERConsumable Parts
27AA8XB08NOZZLEФ3.7G，Consumable PartsR19-037G-155-S
28PZ55161FILTERConsumable Parts
29H1194KPAD, VACUUMKPA-2-N
30AA8XC08NOZZLEФ5.0G，Consumable PartsR19-050G-155-S
31PZ55161FILTERConsumable Parts
32H1339BPAD, VACUUMKPA-3.5-N
33AA8XD09NOZZLEФ7.0G，Consumable PartsR19-070G-155-S
34PZ55161FILTERConsumable Parts
352MGKNY001601SHIM
362MGKNY002500PAD, VACUUM
37AA8XE08NOZZLEФ10.0G，Consumable PartsR19-100G-155-S
38PZ55161FILTERConsumable Parts
392MGKNY001701SHIM
40PG01621PAD, VACUUM
41AA8XF07NOZZLEФ15.0G，Consumable PartsR19-150G-155-S
42PZ55161FILTERConsumable Parts
43PB31612SHIM
44PG01631PAD, VACUUM
452AGKNY009802NOZZLER19-23-10-155S
46PZ55161FILTER
472AGKNY009902NOZZLER19-31-10-155S
48PZ55161FILTER
492AGKNY010002NOZZLER19-43-10-155S
50PZ55161FILTER
512AGKNY010102NOZZLER19-31-13-155S
52PZ55161FILTER
532AGKNY010202NOZZLER19-43-13-155S
54PZ55161FILTER
552AGKNY010302NOZZLER19-59-13-155S
56PZ55161FILTER
572AGKNY010402NOZZLER19-44-18-155S
58PZ55161FILTER
592AGKNY010502NOZZLER19-60-18-155S
60PZ55161FILTER
612AGKNY010602NOZZLER19-84-18-155S
62PZ55161FILTER
632AGKNY010702NOZZLER19-61-25-155S
64PZ55161FILTER
652AGKNY010802NOZZLER19-85-25-155S
66PZ55161FILTER
672AGKNY010902NOZZLER19-115-25-155S
68PZ55161FILTER
692AGKNY011002NOZZLER19-87-37-155S
70PZ55161FILTER
712AGKNY011102NOZZLER19-117-37-155S
72PZ55161FILTER
732AGKNY011202NOZZLER19-118-50-155S
74PZ55161FILTER

FUJI NXT H04-NOZZLES list

No.Part NumberPart NameRemarksRating
1AA06W19NOZZLEConsumable PartsR19-010-155
2PZ55161FILTERConsumable Parts
3AA06X20NOZZLEConsumable PartsR19-013-155
4PZ55161FILTERConsumable Parts
5AA06Y20NOZZLEConsumable PartsR19-018-155
6PZ55161FILTERConsumable Parts
7AA06Z20NOZZLEConsumable PartsR19-025-155
8PZ55161FILTERConsumable Parts
9AA07A21NOZZLEConsumable PartsR19-037-155
10PZ55161FILTERConsumable Parts
11AA07B21NOZZLEConsumable PartsR19-050-155
12PZ55161FILTERConsumable Parts
13AA07C21NOZZLEConsumable PartsR19-070-155
14PZ55161FILTERConsumable Parts
15AA07D20NOZZLEConsumable PartsR19-100-155
16PZ55161FILTERConsumable Parts
17AA07E14NOZZLEConsumable PartsR19-150-155
18PZ55161FILTERConsumable Parts
19AA22Y17NOZZLEФ1.3MELF，ConsumableR19-013M-215
20PZ55161FILTERConsumable Parts
21AA22Z18NOZZLEФ1.8MELF，ConsumableR19-018M-215
22PZ55161FILTERConsumable Parts
23AA2KE12NOZZLEФ2.5MELF，ConsumableR19-025M-215
24PZ55161FILTERConsumable Parts
25AA07F17NOZZLEФ2.5G，Consumable PartsR19-025G-155
26PZ55161FILTERConsumable Parts
27AA07G21NOZZLEФ3.7G，Consumable PartsR19-037G-155
28PZ55161FILTERConsumable Parts
29H1194KPAD, VACUUMKPA-2-N
30AA07H22NOZZLEФ5.0G，Consumable PartsR19-050G-155
31PZ55161FILTERConsumable Parts
32H1339BPAD, VACUUMKPA-3.5-N
33AA07K22NOZZLEФ7.0G，Consumable PartsR19-070G-155
34PZ55161FILTERConsumable Parts
352MGKNY001601SHIM
362MGKNY002500PAD, VACUUM
37AA07L19NOZZLEФ10.0G，Consumable PartsR19-100G-155
38PZ55161FILTERConsumable Parts
392MGKNY001701SHIM
40PG01621PAD, VACUUM
41AA07M15NOZZLEФ15.0G，Consumable PartsR19-150G-155
42PZ55161FILTERConsumable Parts
43PB31612SHIM
44PG01631PAD, VACUUM
452AGKNH014702NOZZLER19-23-10-155
46PZ55161FILTER
472AGKNH014802NOZZLER19-31-10-155
48PZ55161FILTER
492AGKNH014902NOZZLER19-43-10-155
50PZ55161FILTER
512AGKNH015002NOZZLER19-31-13-155
52PZ55161FILTER
532AGKNH015102NOZZLER19-43-13-155
54PZ55161FILTER
552AGKNH015202NOZZLER19-59-13-155
56PZ55161FILTER
572AGKNH015302NOZZLER19-44-18-155
58PZ55161FILTER
592AGKNH015402NOZZLER19-50-18-155
60PZ55161FILTER
612AGKNH015502NOZZLER19-84-18-155
62PZ55161FILTER
632AGKNH015602NOZZLER19-61-25-155
64PZ55161FILTER
652AGKNH015702NOZZLER19-85-25-155
66PZ55161FILTER
672AGKNH015802NOZZLER19-115-25-155
68PZ55161FILTER
692AGKNH015902NOZZLER19-87-37-155
70PZ55161FILTER
712AGKNH016002NOZZLER19-117-37-155
72PZ55161FILTER
732AGKNH016102NOZZLER19-118-50-155
74PZ55161FILTER

FUJI NXT H01/H02-NOZZLES list

No.Part NumberPart NameRemarksRating
1AA0AS16NOZZLEConsumable PartsR36-010-260
2A5188MO RINGConsumable PartsФ2.9×0.8(FKM70)
3AA06815NOZZLEConsumable PartsR36-013-260
4AA0HL11NOZZLEConsumable PartsR36-018-260
5AA0HM12NOZZLEConsumable PartsR36-025-260
6AA0HN11NOZZLEConsumable PartsR36-037-260
7AA0HR12NOZZLEConsumable PartsR36-050-260
8AA08019NOZZLEConsumable PartsR36-070-260
9AA08118NOZZLEConsumable PartsR36-100-260
10AA08212NOZZLER36-150-260, Consumable PartsR36-150-260
11AA08312NOZZLER36-200-260, Consumable PartsR36-200-260
12AA0MZ11NOZZLEФ1.3MELF，ConsumableR36-013M-260
13AA11R12NOZZLEФ1.8MELF，ConsumableR36-018M-260
14AA0ML12NOZZLEФ2.5MELF，ConsumableR36-025M-260
15AA08419NOZZLEФ2.5G，Consumable PartsR36-025G-260
16AA08520NOZZLEФ3.7G，Consumable PartsR36-037G-260
17PB30312SHIM
18H1194KPAD, VACUUMKPA-2-N
19AA07221NOZZLEФ5.0G，Consumable PartsR36-050G-260
20PB30312SHIM
21H1339BPAD, VACUUMKPA-3.5-N
22AA07324NOZZLEФ7.0G，Consumable PartsR36-070G-260
23PB31592SHIM
242MGKNY002500PAD, VACUUM
25AA07422NOZZLEФ10.0G，Consumable PartsR36-100G-260
26PB31602SHIM
27PG01621PAD, VACUUM
28AA07516NOZZLEФ15.0G, Consumable PartsR36-150G-260
29PB31612SHIM
30PG01631PAD, VACUUM
31AA07615NOZZLEФ20.0G, Consumable PartsR36-200G-260
32PB31732SHIM
33PG01641PAD, VACUUM
34AA5EB04NOZZLEConsumable PartsR36-070-180
35AA5EC03NOZZLEConsumable PartsR36-100-180
36AA5ED02NOZZLEConsumable PartsR36-150-180
37AA5EE01NOZZLEConsumable PartsR36-200-180
38AA6NE04NOZZLEФ7.0G，Consumable PartsR36-070G-180
39PB31592SHIM
402MGKNY002500PAD, VACUUM
41AA6NF03NOZZLEФ10.0G，Consumable PartsR36-100G-180
42PB31602SHIM
43PG01621PAD, VACUUM
44AA6NG02NOZZLEФ15.0G，Consumable PartsR36-150G-180
45PB31612SHIM
46PG01631PAD, VACUUM
47AA6NH01NOZZLEФ20.0G，Consumable PartsR36-200G-180
48PB31732SHIM
49PG01641PAD, VACUUM

Updated Date: 2023-04-25

Get Quote

Leave us a message, we will get back to you ASAP!

    Related products
