Description
We offer Assembleon Sapphire and Comet Yamaha YV112 Type 51 Nozzle 5332 360 10335 533236010335 for SMT pick and place machine, send us your inquiry if you cannot find what you are looking for.
The whole series Assembleon/Yamaha nozzles list below for your reference.
Yamaha Nozzles list, 300 Series
No. Part Number Part Name Remark 1 KHN-M7710-A1 ASSY 301A NOZZLE TYPE 301A 2 KHN-M7720-A1 NOZZLE 302A ASSY TYPE 302A 3 KHY-M7740-A0 NOZZLE 303A/314A ASSY TYPE 303A/314A 4 KHY-M7750-A0 NOZZLE 304A/315A ASSY TYPE 304A/315A 5 KHY-M7770-A0 NOZZLE 306A/317A ASSY TYPE 306A/317A 6 KHY-M77A0-A0 NOZZLE 310A ASSY TYPE 310A（Narrow adjacent Type） 7 KHY-M7710-A0 NOZZLE 311A ASSY TYPE 311A（Narrow adjacent Type） 8 KHY-M7720-A0 NOZZLE 312A ASSY TYPE 312A（Narrow adjacent Type） 9 KHY-M7730-A0 NOZZLE 313A ASSY TYPE 313A（Narrow adjacent Type）
Yamaha Nozzles list, 30 Series
No. Part Number Part Name Remark 1 KM0-M711A-31X FLOATING NOZZLE(for Head1) TYPE 31 2 KM0-M711A-03X NOZZLE A TYPE 31 3 KM0-M711C-02X NOZZLE C TYPE 32-2 4 KM0-M711D-00X NOZZLE D COMP TYPE 33 5 KM0-M711E-00X NOZZLE COMP Type 34 6 KM0-M71AB-A0X NOZZLE AB Type 35
Yamaha Nozzles list, 30 Series
No. Part Number Part Name Remark 1 KV7-M71N1-A0X NOZZLE 61F ASSY TYPE 61F 2 KV7-M71N2-A0X NOZZLE 62F ASSY TYPE 62F 3 KV7-M71N3-A0X NOZZLE 63F ASSY TYPE 63F 4 KV7-M71N4-A0X NOZZLE 64F ASSY TYPE 64F 5 KV7-M71N5-A0X NOZZLE 65F ASSY TYPE 65F
Yamaha Nozzles list, 70 Series
No. Part Number Part Name Remark 1 KV8-M7710-A1X NOZZLE 71A ASSY. 2 KV8-M7720-A1X NOZZLE 72A ASSY 3 KV8-M7730-00X NOZZLE 73A 4 KV8-M7740-A0X NOZZLE 74A ASSY 5 KV8-M7741-00X NOZZLE 74A 6 KV8-M7760-00X NOZZLE 76A 7 KV8-M77WL-A0X CIRCLE NOZZLE 7A
Yamaha Nozzles list, 70 Series for FNC
No. Part Number Part Name Remark 1 KV8-M71N1-A0X NOZZLE 71F ASSY TYPE 71F 2 KV8-M71N2-A0X NOZZLE 72F ASSY TYPE 72F 3 KV8-M71N3-A0X NOZZLE 73F ASSY TYPE 73F 4 KV8-M71N9-A1X NOZZLE 79F ASSY TYPE 79F
Yamaha Nozzles list, 60 Series
No. Part Number Part Name Remark 1 KV7-M7710-A1X NOZZLE 61A ASSY 2 KV7-M7720-A1X NOZZLE 62A ASSY 3 KV7-M7730-00X NOZZLE 63A 4 KV7-M7740-A0X NOZZLE 64A ASSY
Yamaha Nozzles list, 130 Series
No. Part Number Part Name Remark 1 KW7-M7811-00X NOZZLE, 2 SHOT 1608 Type 131 2 KW7-M7812-00X NOZZLE, 2 SHOT 3216 Type 132 3 KW7-M7813-00X NOZZLE, 2 SHOT LARGE Type 133 4 KW7-M7814-00X NOZZLE, 1 SHOT 0.4 Type 134 5 KW7-M7815-00X NOZZLE, 1 SHOT 0.8 Type 135 6 KW7-M7816-00X NOZZLE, 1 SHOT 1.5 Type 136 7 KGK-M7836-00X NOZZLE, HN04 ASSY Type 139 8 KGK-M7819-00X BODY NOZZLE HN for Type 139
Yamaha Nozzles list, 200 Series
No. Part Number Part Name Remark 1 KGT-M7710-A0X NOZZLE 201A ASSY Type 201A 2 KGT-M7720-A0X NOZZLE 202A ASSY Type 202A 3 KGT-M7730-A1X NOZZLE 203A ASSY Type 203A 4 KGT-M7760-A0X NOZZLE 206A ASSY Type 206A 5 KGT-M7790-A0X NOZZLE 209A ASSY Type 209A 6 KV8-M71U0-01X NOZZLE ASSY 71/ 72/ 73F 7 KV8-M71U0-10X NOZZLE ASSY 71/ 79/ 73F
